FD600 yog IP65 siab tiv thaiv zaus inverter tsim rau qhov chaw hnyav xws li hlau, roj av, thiab tshuaj lom neeg kev lag luam, uas tej zaum yuav raug dej los yog roj pos huab, nrog rau plua plav thiab oily daim ntaub ntawv xws li papermaking, zaj duab xis, thiab txheej. Nws cov pawg thawj coj saib xyuas tau coated nrog cov kws tshaj lij- qib kev sib xyaw ua ke, muab ntau yam kev tiv thaiv, ua kom lub neej ntev ntawm kev tsav tsheb. Tag nrho chav tsev yog resistant rau oxidation, ntsev tsuag, pwm, tshav kub, noo noo, thiab corrosion.

Nta

Yooj yim rau nruab / Tswj

Hlau vaj tse, kev tsim qauv ntawm lub txee tswj thiab inverter, zam kev teeb tsa theem nrab, txuag nqi kev teeb tsa, thiab kev tsim tag nrho yog kev saib xyuas - dawb.

Yooj yim rau kev khiav lag luam

Pib / nres ua haujlwm, 7 theem ntawm kev ua haujlwm nrog nce thiab nqis yuam sij.

Ua tiav Kev Tiv Thaiv

Txog 33 kev tiv thaiv suav nrog kev tiv thaiv- kev sib tsoo, overcurrent, overvoltage, overload, thiab grounding.

Siab Flexibility

Ib lub tshuab tuaj yeem siv rau ntau lub hom phiaj. Koj tsuas yog yuav tsum tau teeb tsa cov kev hloov pauv ntawm kev tswj hwm synchronous motors thiab asynchronous motors.

Centralized tswj

Xaiv qhov chaw nres tsheb wireless kom ua tiav qhov kev tswj hwm ntawm kev sib kis wireless.

VVC Control Algorithm

Raws li tus tshiab ruaj khov hlau nplaum synchronous lub cev muaj zog VVC tswj algorithm, nws tso tseg cov tsoos SVC qhov kev cia siab ntawm lub cev muaj zog, thiab lub tshuab synchronous kuj tuaj yeem ua tiav kev tswj hwm zoo yam tsis muaj kev sib tw.

Anti-ntau dhau

Tshwj xeeb tam sim no limiting tswj algorithm xyuas kom meej tias lub cev muaj zog tsis khiav hauv overcurrent, tiv thaiv lub cev los ntawm demagnetizing vim overloading cua sov, thiab txo cov txij nkawm los ntawm demagnetization.

8.4G IoT daim npav

Nws tuaj yeem paub txog IoT tswj, pib thiab nres, kev tswj ceev, kev saib xyuas cov ntaub ntawv thiab lwm yam haujlwm.

product-874-393

product-1152-473

Txhawb nqa Anti-Swaying Functions rau ntau yam txheej txheem Networks

Specifications

Qhov project		Specification
Tswj yam ntxwv	Tswj txoj kev	Qhib lub voj vector	V/F tswj	Kaw lub voj vector * 0.00Hz 180%
	Pib Torque	0.5Hz 180%	0.5Hz 150%
	Ceev Range	1:100	1:100	1:1000
	Kev nrawm nrawm nrawm	±0.5%	-	±0.02%
	Torque Accuracy	±5%	-	±2%
	Hom Tsav	AC asynchronous lub cev muaj zog, AC ruaj khov hlau nplaum synchronous lub cev muaj zog
Kev tsim qauv tsim	Ntau zaus	General vector tswj: 500Hz V / f tswj: 5000Hz
	Kev daws teeb meem zaus	Kev teeb tsa digital: 0.01Hz Analog teeb tsa: Ntau zaus × 0.025%
	Carrier Frequency	0.5K-16KHz, cov cab kuj zaus tuaj yeem hloov kho raws li qhov kub thiab txias
	Txoj kev teeb tsa zaus	Kev ua haujlwm vaj huam sib luag, analog AI1, AI2 (optional expansion card yuav tsum), vaj huam sib luag UP / DN tswj, kev sib txuas lus,
	Acceleration thiab Deceleration yam ntxwv	Linear los yog S-curve acceleration/deceleration mode Time range: 0.0-65000S
	V/F nkhaus	Peb txoj kev: linear, multi-point, thiab N-power
	Kev sib cais V/F	2 txoj kev: kev sib cais tag nrho, ib nrab- sib cais
	DC Braking peev xwm	DC braking zaus: 0.0-300Hz DC braking tam sim no: 0.0% -100%
	Kev Tswjhwm	Jog zaus: 0.0-50.00Hz Jog acceleration / deceleration lub sij hawm: 0.0-6500S
	Ua - hauv PID	Nws tuaj yeem paub tau yooj yim kaw - voj tswj lub siab, ntws, kub, thiab lwm yam.
	PLC Ntau- nrawm	Los ntawm kev tsim-hauv PLC lossis tswj cov chaw nres tsheb, mus txog 16 cov kauj ruam nrawm tuaj yeem ua tiav
	Common DC Bus *	Ntau lub inverters sib koom tib lub tsheb npav DC, thiab lub zog tau txais kev sib npaug
	Tsis Siv Neeg Voltage Regulator (AVR)	Thaum daim phiaj hluav taws xob hloov pauv, nws tuaj yeem ua kom cov zis hluav taws xob ruaj khov
	Tshaj peev xwm	G hom: 150% ntsuas tam sim no 60S; 180% ntsuas tam sim no 3S P- hom tshuab: 120% ntsuas tam sim no 60S ; 150% ntsuas tam sim no 3S
	Overvoltage thiab Overspeed Stall Control	Tsis siv neeg txwv qhov tam sim no thiab voltage thaum lub sijhawm ua haujlwm los tiv thaiv kev tiv thaiv overcurrent thiab overvoltage
	Fast Current Limiting Function	Txo cov overcurrent faults, xyuas kom meej tias lub module tsis puas ntau npaum li sai tau, thiab tiv thaiv lub cev ua haujlwm ntawm inverter
	Torque txwv thiab tswj	Lub "excavator" feature cia li txwv lub torque thaum lub sij hawm ua hauj lwm los tiv thaiv tsis tu ncua overcurrent tripping; lub vector tswj hom tuaj yeem ua tiav torque tswj.
Nta	Tus neeg siv -tus phooj ywg interface	Thaum lub zog rau, kev sib tham tus phooj ywg "HELLO" yuav tshwm sim. Nias tus yuam sij PRG los tso saib tsuas yog cov txheej txheem tsis tau. Nias thiab tuav rau ntau tshaj 2 vib nas this los tso saib tag nrho cov pawg parameter.
	FWD/REV	Hloov mus rau pem hauv ntej thiab thim rov qab, nias ntev 2S hloov los ntawm hom ceev mus rau hom siab tas li
	Lub Sijhawm Tswjhwm Ua Haujlwm	Nias lub khawm nce / nqis los teeb tsa lub sijhawm khiav thiab nres lub sijhawm.
	4 Txheej ntawm Tsav Tsheb Parameters	Muaj peev xwm paub hloov kev tswj ntawm 4 pawg ntawm cov motors, nrog rau kev xaiv hom kev tswj
	4G Card Chaw Taws Teeb Sib Txuas Lus	Siv 4G daim npav kom paub txog kev sib txuas lus mobile APP
	Dej twj tso kua mis tiv thaiv	Kev tiv thaiv lub twj tso kua mis qhuav, tag nrho cov dej theem / dej tsis muaj kev tiv thaiv, thaiv rotor tiv thaiv
	Lus txib Source	Txhawb kev lag luam vaj huam sib luag, tswj lub davhlau ya nyob twg, serial kev sib txuas lus teeb tsa,
	Ntau qhov chaw	Kev teeb tsa digital, analog voltage, analog tam sim no, kev sib txuas lus sib txuas, pab pawg zaus qhov sib ntxiv lossis rho tawm, thiab tuaj yeem hloov pauv ntawm ib leeg.
	Kev khiav ceev	Tsis muaj cov lus tawm tswv yim sab nraud yuav tsum tau pib lub tshuab rotating smoothly thiab tsis muaj kev cuam tshuam
	Kev tiv thaiv muaj nuj nqi	Fais fab - ntawm lub cev muaj zog tiv thaiv luv luv Circuit Court, kev tawm tswv yim thiab tso tawm theem tsis muaj kev tiv thaiv, tiv thaiv overcurrent, tiv thaiv overvoltage, tiv thaiv undervoltage, tiv thaiv overheating, tiv thaiv overload
Ib puag ncig	Qhov chaw siv	Nyob sab hauv tsev, deb ntawm tshav ntuj ncaj qha, plua plav, corrosive gas, nplaim taws, roj pos huab, dej vapor, dej ntws los yog ntsev
	Qhov siab	Tsis muaj derating yuav tsum tau rau qhov siab tshaj 1000m; rau qhov siab tshaj 1000m, derating los ntawm 1% yog yuav tsum tau rau txhua txhua 100m nce nyob rau hauv qhov siab.
	Ambient Kub	-10℃~ +40℃Siv ntawm derating ntawm 40℃thiab 50℃. Rau txhua txhua 1℃nce, cov zis tam sim no yuav txo qis los ntawm 1%.
	Cov av noo	Tsawg dua 95% RH, tsis muaj condensation
	Cia	-40-+70 degree

Daim ntawv thov Scenario

Roj-cov twj tso kua mis siv rau hauv kev tswj cov tshuab hauv cov hlau, roj av, thiab tshuaj lom neeg kev lag luam tuaj yeem txhim kho kev ua haujlwm zoo, txuag hluav taws xob thiab txo kev noj, thiab ua tiav kev tswj hwm ntau dua, xws li:

Submersiblee Electric Pumps: oilfield pumping units, deep well pumps, etc., yuav tsum tau hloov mus rau siab -cov kua viscosity thiab cov khoom sib txawv.
Lubrication System: quab yuam lubrication ntawm cov khoom lag luam (xws li gearboxes thiab bearings) yuav tsum muaj roj ruaj khov.
Hydraulic System: Cov roj twj tso kua mis tso zis yog kho los ntawm zaus hloov dua siab tshiab, hloov cov kev tswj qhov sib npaug ntawm qhov qub.
Cooling System: Kho cov roj twj tso kua mis ntws raws li qhov ntsuas kub tawm los txhawm rau txhim kho thermal tswj.
Siv rau hauv ziab / ntxuav cov cuab yeej hauv papermaking, zaj duab xis, txheej thiab lwm yam lag luam tuaj yeem txhim kho qhov tseeb ntawm huab cua ntim tswj thiab kev siv hluav taws xob, xws li:

Corrosion-resistant papermaking kev lag luam: cua riam ziab tom qab lub qhov cub, lub inverter kho cua ceev raws li cov av noo ntawm daim ntawv web;

Lithium roj teeb txheej: cua riam phom tshem tawm tom qab electrode txheej yuav tsum tau synchronized nrog reeling thiab unreeling ceev;

Yas zaj duab xis ntau lawm: Cua riam tswj cov yeeb yaj kiab thickness uniformity, thiab lub sij hawm teb yuav tsum yog<100ms.

Qhov ntev

product-466-154

Kev xaiv qauv

Mua odel	Universal Phab Ntsa Mount Installation Diagram						Plat -ntevFua ixedIkev txhim kho
	Kev teeb tsaSizemm		Zuag qhia tag nrhoDQhov siab (mm)				Zuag qhia tag nrhoDkev xav(mm)
	W1	H1	W	H	D	ntsia liaj qhov rooj	W2	H2	D2
FD600-4T4.0G	170	/	190	265	114	M5	/	/	/
FD600-4T5.5G
FD600-4T7.5G	180	/	201	304	137	M6	178	304	137
FD600-4T11G
